Located in the heart of Safat, Kuwait, Shiraz Flanges stands as your trusted partner for industrial piping solutions. We specialize in the manufacturing and supply of high-integrity components, with a particular strength in our DIN 2527 PN25 Blind Flanges. Crafted to meet the most stringent international standards, these flanges are designed for reliability and long-term performance. We understand the critical demands of Kuwait’s diverse industries, and our commitment is to deliver products that ensure operational safety and efficiency in every application, backed by our local expertise and dependable service.
Our DIN 2527 PN25 Blind Flanges are engineered from robust materials like carbon steel, often conforming to grades such as S235JR or similar, ensuring a solid composition for heavy-duty use. They are meticulously heat-treated to achieve superior mechanical properties, including high tensile strength and excellent yield strength. This careful processing guarantees they can withstand significant pressure loads up to 25 bar at elevated temperatures without deforming. The result is a component that offers exceptional durability and resilience, providing a dependable seal in the most demanding pipeline systems.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| DIN 2527 PN25 (in mm) | ||||||
| Nominal Pipe Size | Flange Dia | Thk of Flange | Dia of Bolt Circle | No. of | Dia of Bolt Holes | |
| DIN | D | B | K | holes | D2 | KG |
| 90 | 90 | 16 | 60 | 4 | 14 | 0.72 |
| 95 | 95 | 16 | 65 | 4 | 14 | 0.81 |
| 105 | 105 | 18 | 75 | 4 | 14 | 1.14 |
| 115 | 115 | 18 | 85 | 4 | 14 | 1.38 |
| 140 | 140 | 18 | 100 | 4 | 18 | 2.03 |
| 150 | 150 | 18 | 110 | 4 | 18 | 2.35 |
| 165 | 165 | 20 | 125 | 4 | 18 | 3.20 |
| 185 | 185 | 22 | 145 | 4 | 18 | 4.29 |
| 200 | 200 | 24 | 160 | 8 | 18 | 5.54 |
| 235 | 220 | 24 | 190 | 8 | 22 | 7.60 |
| 270 | 250 | 26 | 220 | 8 | 26 | 10.82 |
| 300 | 285 | 28 | 250 | 8 | 26 | 14.60 |
| 330 | 315 | 28 | 280 | 8 | 26 | 17.40 |
| 360 | 340 | 30 | 310 | 12 | 26 | 22.47 |
| 425 | 405 | 32 | 370 | 12 | 30 | 33.51 |
| 485 | 460 | 34 | 430 | 12 | 30 | 46.29 |
| 555 | 520 | 38 | 490 | 16 | 33 | 68.08 |
| 620 | 580 | 40 | 550 | 16 | 36 | 89.59 |
| 730 | 715 | 45 | 660 | 20 | 36 | 140.66 |
| 845 | 780 | 48 | 770 | 20 | 39 | 202.30 |
| 960 | 895 | 50 | 875 | 24 | 42 | 271.05 |
| 1085 | 1015 | 54 | 990 | 24 | 48 | 373.52 |
| 1185 | 1115 | 58 | 1090 | 28 | 48 | 479.07 |
| 1320 | 1230 | 62 | 1210 | 28 | 56 | 632.47 |
Shiraz Flanges, a leading supplier in Safat, Kuwait, offers an extensive selection of DIN 2527 PN25 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN25 Blind Flanges are used to seal the ends of pipelines, valves, and equipment in moderate to high-pressure systems. They are widely employed in industries such as oil and gas, petrochemical, and water treatment for isolating sections of pipelines during maintenance, inspection, or repair. These flanges prevent leaks, contamination, and ensure the integrity of the system. Their durable construction and reliable sealing capabilities make them an essential component for managing pressure and maintaining operational efficiency in various industrial applications.
Yes, we offer custom sizes for DIN 2527 PN25 Blind Flanges to meet specific project needs. Our team at Shiraz Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shirazflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
