With a reputation for reliability, Shiraz Flanges in Safat, Kuwait is a trusted name for industrial components. The company stands out for its supply of high-grade DIN 2635 PN40 Weld Neck Flanges. These are crucial elements designed for demanding scenarios, ensuring secure and lasting connections in pipelines. Understanding the needs of Kuwait’s industrial sector, Shiraz Flanges provides solutions that prioritize safety and performance, making them a go-to partner for projects where precision and durability cannot be compromised.
Crafted from robust materials like carbon or stainless steel, these flanges are engineered for strength. Their composition ensures excellent resistance to stress under high pressure, aligning with the PN40 rating. The mechanical properties are carefully controlled to meet the exacting standards of DIN 2635, guaranteeing they can handle significant loads and maintain a tight seal. This makes them reliable under tough operating conditions where failure is not an option.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 95 | 16 | 65 | 38 | 30 | 2 | 4 | 6 | 45 | 2 | 4 | M 12 | 14 | 0,746 |
| 21,3 | – | 32 | ||||||||||||||
| 20 | – | 25 | 105 | 18 | 75 | 40 | 38 | 2,3 | 4 | 6 | 58 | 2 | 4 | M 12 | 14 | 1,06 |
| 26,9 | – | 40 | ||||||||||||||
| 25 | – | 30 | 115 | 18 | 85 | 40 | 42 | 2,6 | 4 | 6 | 68 | 2 | 4 | M 12 | 14 | 1,29 |
| 33,7 | – | 45 | ||||||||||||||
| 32 | – | 38 | 140 | 18 | 100 | 42 | 52 | 2,6 | 6 | 6 | 78 | 2 | 4 | M 16 | 18 | 1,88 |
| 42,4 | – | 56 | ||||||||||||||
| 40 | – | 44,5 | 150 | 18 | 110 | 45 | 60 | 2,6 | 6 | 7 | 88 | 3 | 4 | M 16 | 18 | 2,33 |
| 48,3 | – | 64 | ||||||||||||||
| 50 | – | 57 | 165 | 20 | 125 | 48 | 72 | 2,9 | 6 | 8 | 102 | 3 | 4 | M 16 | 18 | 2,82 |
| 60,3 | – | 75 | ||||||||||||||
| 65 | 76,1 | – | 185 | 22 | 145 | 52 | 90 | 2,9 | 6 | 10 | 122 | 3 | 8 | M 16 | 18 | 3,74 |
| 80 | 88,9 | – | 200 | 24 | 160 | 58 | 105 | 3,2 | 8 | 12 | 138 | 3 | 8 | M 16 | 18 | 4,75 |
| 100 | – | 108 | 235 | 24 | 190 | 65 | 128 | 3,6 | 8 | 12 | 162 | 3 | 8 | M 20 | 22 | 6,52 |
| 114,3 | – | 134 | ||||||||||||||
| 125 | – | 133 | 270 | 26 | 220 | 68 | 155 | 4 | 8 | 12 | 188 | 3 | 8 | M 24 | 26 | 9,07 |
| 139,7 | – | 162 | ||||||||||||||
| 150 | – | 159 | 300 | 28 | 250 | 75 | 182 | 4,5 | 10 | 12 | 218 | 3 | 8 | M 24 | 26 | 11,8 |
| 168,3 | – | 192 | ||||||||||||||
| (175) | 193,7 | – | 350 | 32 | 295 | 82 | 218 | 5,6 | 10 | 15 | 260 | 3 | 12 | M 27 | 30 | 18,2 |
| 200 | 219,1 | – | 375 | 34 | 320 | 88 | 244 | 6,3 | 10 | 16 | 285 | 3 | 12 | M 27 | 30 | 21,5 |
| 250 | – | 267 | 450 | 38 | 385 | 105 | 298 | 7,1 | 12 | 18 | 345 | 3 | 12 | M 30 | 33 | 34,9 |
| 273 | – | 306 | ||||||||||||||
| 300 | 323,9 | – | 515 | 42 | 450 | 115 | 362 | 8 | 12 | 18 | 410 | 4 | 16 | M 30 | 33 | 49,7 |
| 350 | 355,6 | – | 580 | 46 | 510 | 125 | 408 | 8,8 | 12 | 20 | 465 | 4 | 16 | M 33 | 36 | 68,1 |
| – | 368 | |||||||||||||||
| 400 | 406,4 | – | 660 | 50 | 585 | 135 | 462 | 11 | 12 | 20 | 535 | 4 | 16 | M 36 | 39 | 96,5 |
| – | 419 | |||||||||||||||
| (450) | 457 | – | 685 | 50 | 610 | 135 | 500 | 12,5 | 12 | 20 | 560 | 4 | 20 | M 36 | 39 | 99,7 |
| 500 | 508 | – | 755 | 52 | 670 | 140 | 562 | 14,2 | 12 | 20 | 615 | 4 | 20 | M 39 | 42 | 117 |
Shiraz Flanges, a leading supplier in Safat, Kuwait, offers an extensive selection of DIN 2635 PN40 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2635 PN40 Weld Neck Flanges are primarily used in high-pressure piping systems across industries such as oil and gas, petrochemical, power generation, and chemical processing. Their robust design ensures secure, leak-proof connections between pipes, valves, and other equipment in demanding environments exposed to high pressure, temperature, and fluctuating conditions. These flanges are commonly installed in critical systems like pipelines, reactors, compressors, and pumps, where performance and reliability are paramount. Their durability and precision make them essential for maintaining system integrity and long-term operational efficiency.
Yes, we offer custom sizes for DIN 2635 PN40 Weld Neck Flanges to meet specific project needs. Our team at Shiraz Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@shirazflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2635 PN40 WNRF Flanges Supplier in Safat | Alloy Steel DIN 2635 PN40 Weld Neck Flanges Manufacturer in Kuwait |
| Nickel Alloy DIN 2635 PN40 Welding Neck Flange | Mild Steel DIN 2635 PN40 Weld Neck Flange |
| 30 inch DIN 2635 PN40 Weld Neck Flange Dealer | Raised Face DIN 2635 PN40 Weld Neck Flanges Manufacturer |
| ASME SA105N Raised Faced DIN 2635 PN40 Weld Neck Flanges | 18 inch Carbon Steel DIN 2635 PN40 Weld Neck Flange |
| 18 inch DIN 2635 PN40 Carbon Steel Weld Neck Flange | DIN 2635 PN40 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2635 PN40 Welding Neck Flanges | Copper Nickel DIN 2635 PN40 Weld Neck Flanges at Best Price |
| DIN 2635 PN40 Welding Neck FF Flange Supplier | Suppliers of DIN 2635 PN40 Weld Neck Flange |
| DIN 2635 PN40 WNRF Flanges Distributor in Jahra | Flat Face DIN 2635 PN40 Weld Neck Flanges Exporter |
| Carbon Steel DIN 2635 PN40 Welding Neck Flange | DIN 2635 PN40 Weld Neck RF Flange Supplier |
| Raised Face DIN 2635 PN40 Weld Neck Plate Flanges | Titanium DIN 2635 PN40 Welding Neck Flanges |
| DIN 2635 PN40 WNRF Flange Stockist in Kuwait | Raised Faced DIN 2635 PN40 Slip-On flanges Dealer in Kuwait |
| 4 inch Stainless Steel DIN 2635 PN40 Weld Neck Flange | DIN 2635 PN40 Weld Neck RF Flanges Stockholder |
| DIN 2635 PN40 Welding Neck Flanges Supplier in Hawalli | MS DIN 2635 PN40 Weld Neck Flange |
| DIN 2635 PN40 Large Diameter Weld Neck Flange | 30 Inch DIN 2635 PN40 Weld Neck Pipe Flange Dimensions |
| DIN 2635 PN40 WNRF Flange Exporter | DIN 2635 PN40 Weld Neck Flange Pressure Ratings |
| Carbon Steel Raised Face DIN 2635 PN40 Weld Neck Flange Stockist | Duplex Steel DIN 2635 PN40 WNRF Flanges Supplier in mm |
| DIN 2635 PN40 Weld Neck Pipe Flanges Wholesaler | DIN 2635 PN40 WNRF Flanges Supplier |
| DIN 2635 PN40 Weld Neck Flange Manufacturer | Flat Face DIN 2635 PN40 Weld Neck Flange Manufacturer |
| Stainless Steel DIN 2635 PN40 Weld Neck Flange | ASTM B564 Raised Faced DIN 2635 PN40 Weld Neck Flanges |
| DIN 2635 PN40 Weld Neck Flange Dimensions | Raised Face DIN 2635 PN40 Weld Neck Flange Manufacturer |
| 8 Inch DIN 2635 PN40 Welding Neck Pipe Flanges | DIN 2635 PN40 Weld Neck Flanges Stockist |
| DIN 2635 PN40 Weld Neck Pipe Flanges Supplier in Al Ahmadi | Duplex Steel DIN 2635 PN40 Weld Neck Flanges |
| German Standard DIN 2635 PN40 Weld Neck Flanges | DIN 2635 PN40 Weld Neck Flange Supplier in Kuwait |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
